Memphis MP/Union Railway Maps

Contributed by Bill Strong
Union Railway map of downtown Memphis in the 1930s. Larger version.

Contributed by Bill Strong
Memphis Union Railway Industrial map. Larger Version

Contributed by Bill Pollard
Map of Sargent yard roundhouse area, from a 1945 Union Railway agreement with BLF&E.

Contributed by Bill Pollard
MP Georgia Street Yard, October 1964.
By the time this drawing was made, the building labeled "Passenger Station" was in fact the "former" passenger station.

Contributed by Bill Pollard
Salvaged from Little Rock Union Depot trash can in late 1960s.

Union Ry. North Yard, just east of better known IC North Yard. Larger View

Union Ry. Poplar Street Station area. Larger View

Union Ry. river front joint trackage. The track nearest the river is labeled joint Union Ry, Frisco, etc. Larger View

Union Ry. Broadway east track. Larger View

Union Ry. Binghampton trackage, east side of loop. Larger View

Union Ry. Ford Motor trackage. Larger View

Union Ry. Joint industrial trackage in south west downtown. Larger View

Contributed by Bill Pollard
"Broadway" in 1915

Contributed by Bill Pollard
"Broadway" in 1915
