Memphis Union Station Tower 17
 |
Contributed by Bill Strong |
View appears to be from Tower 17 |
 |
 |
Contributed by David Johnston |
The bottom image was created by "zooming-in" on Tower-17 in the background of a 5/73 shot from Signal Bridge A that is posted on the "Broadway-IC Crossing Page"and is duplicated above. |
 |
Contributed by Bill Pollard |
This image is taken from the July 1944 NC&StL Bulletin covering their Memphis Yards. |
 |
 |
Contributed by Eric Fleet |
Taken from Nashville, Chattanooga & St. Louis Railway Rules of the Transportation Department, Effective April 1, 1952. |
Memphis Union Station Co - Electro-Pneumatic Interlocking
Union Switch & Signal Company mechanism -- 107 lever machine
51 levers for 35 switches, 8 double and 9 single slips, and 6 derails
34 levers for 34 signals
1 spare lever
21 spare spaces
We need a good image of this tower!
For information about the Memphis Central Station.
For information about the Other Passenger Stations of Memphis.
